2MP Uncooled Long-rang High Clarity 1920×1080 Gyro-Stabilized Marine Thermal Camera with Auto Tracking for Shipping Security

Day Camera

Sensor type

1/2" Progressive Scan CMOS

Pixel

2MP

Frame rate

50/60Hz

Minimum illumination

Color: 0.001 lux @ (F1.5, AGC ON); B/W: 0.0001   lux @ (F1.5, AGC ON)

Resolution

1920(H) × 1080(V)

Focal length

6mm～210mm

Zoom speed

4.5s±0.5s (Wide-Tele)

Optical/Digital zoom

35×/16×

Iris

F1.5～F4.8

FOV

61.9°×37.2°～1.9°×1.1°(Wide-Tele)

Minimum working distance

1m～5m (Wide-Tele)

Focus

Auto/Manual/Semi-auto

Thermal   Camera

Detector type

Uncooled Vanadium Oxide Microbolometer

Resolution

1280 × 1024@12μm

Spectrum

8～14μm

NETD

≤40mK@F1.0,300K

Focal length

45mm/135mm

FOV

19.4°×15.6°/6.5°×5.2°

Field of view   switching time

≤0.8s

Frame rate

25Hz

Focus

Auto/Manual

Digital zoom

1×/2×/4×/8×

Pseudo

White Hot / Black Hot / Rainbow / Iron Red / Lava   / Sky / Purple Orange / Gradient Red / Gradient Green / Gradient Blue

Image process

Non-uniformity Correction/Digital Filter Noise   Reduction/DDE

Pan-Tilt

Platform

2-axis

Stable accuracy

≤0.5mrad

Pan speed

0.003°～100°/s (customization supported)

Tilt speed

0.003°～100°/s (customization supported)

Pan accelerate speed

≥80°/s²

Tilt accelerate speed

≥80°/s²

Repeat positioning accuracy

±0.003°

Position Resolution

0.00035°

Driving forms

Direct   drive

Preset

Max 256

Pan/ Tilt

360° rotating continuously / -75°～+75°

Patrol scanning

8 patrols, up to 32 presets for each patrol

LRF

Operating Wavelength

1535 nm ± 10 nm

Maximum Range Measurement Capability

≥3000m

The measurement performance is tested using a   2.3m × 2.3m target board (or equivalent target) with a reflectivity of 0.3,   under environmental conditions of visibility ≥12 km and relative humidity   ≤60%.

Minimum Range Measurement Distance

≤20m

Measurement Accuracy

≤±1m

Detection Probability

≥98%

Measurement Frequency

Single-shot, 1Hz, 5Hz, 10Hz selectable

Target   recognition and tracking

Supported Target Types

Personnel, vehicles, vessels, aircraft, and   other moving targets

Multi-Target Capability

Supports simultaneous detection and   tracking of multiple targets

Detection ROI

Configurable rectangular Region of Interest   (ROI)

Detectable Target Size

2×2 pixels to 200×100 pixels

Detection Algorithms

Grayscale analysis, motion detection, and   contour-based detection

Tracking Algorithms

Phase correlation, centroid tracking, and   color feature matching

Tracking Target Size

2×2 pixels to 200×100 pixels

Tracking Accuracy

≤0.15 mrad (Line-of-Sight tracking   accuracy)

General

Encode

H.265/H.264

Interface protocols

ONVIF,   НТТР, TCP/IP, UDP, RTP, RTSP, RTCP, DNS, DDNS, DHCP, FTP, NTP, PPPOE, SMTP,   UPNP;

Communication

1×RJ45/1×RS422/2×SDI (customization   supported)

Power

DC24V

RH

<95%RH

Protection grade

IP66

Anti-salt-fog

PH value 6.5～7.2, continuous   spraying for 48 hours, no surface change

Operation temp

-40℃～+55℃

Storage temp

-55℃～+65℃

Consumption

≤50W Static / ≤200W Peak

Weight

≤25Kg

Dimension

Φ310mm × 450mm
